Fire Alarm Circuits (Nav)
Fire alarms have come a long way from when they were first invented, having gone from pull rods to AI powred fire detectors. This navigation discusses the most basic version of fire alarm wiring, including conventional & adressable systems.
Terms
- Adressable Fire Alarm System
- 1. Uses user-set programing to allow for larger complex systems, less wiring, and.more customizability
- 2. Allows for pinpoint location tracking of a ongoing fire
- 3. Typically more expensive, used for larger locations
- Conventional Fire Alarm System
- 1. Uses relays and conductivity between circuits to determine when a fire is reported (through a pull station, smoke, etc)
- 2. Has a group of zones that gives a general location of a fire
- 3. Typically cheaper, used more for smaller locations
Tutorials
Panel Setup
The basic wiring of a fire alarm panel.Check it out!
Pull Stations
How to wire a pull station into a fire alarm system.Check it out!
Smoke Alarm
How to wire a smoke alarm into a fire alarm system.Check it out!
Pressure Switch
How to wire a water pressure switch into a fire alarm system, typically used for sprinkler detection.Check it out!
Door Magnets
How to wire a system that allows for the closing of door magnets durring a fire.Check it out!
Annunciators
How to wire a remote annunciators into a fire alarm system.Check it out!
Programing
How to program a fire alarm system.Check it out!
